| Bucket Capacity: 0.28/0.32m³ |
| Machine Weight : 7500kg |
| Year: 2026 |
| Brand: LIUGONG |
| Shipping: Bulk cargo / Container/Flat Rack |
LIUGONG 9075F(Yuchai)
Why Choose Us
We have a strong mechanical team to ensure that all machines are well maintained, of high quality, and 100% original.
Spare parts are available, the most suitable for your machine.
We offer almost all types of second-hand construction machinery in good condition and at low prices.
Product Introduction
| Machine weight | 7500 kg |
| power | 36.8 kW @ 2200 rpm |
| Standard bucket capacity | 0.28/0.32 m³ |
| Engine Model | Yuchai YCF3050 |
| Emission standards | National IV |
| Type | Vertical, upright, water-cooled, four-stroke, turbocharged |
| Rated power (rated speed) | 36.8 kW @ 2200rpm |
| Maximum torque (torque/speed) | 240 N·m @ 1200-1400 rpm |
| Cooling method | Water cooling |
| Rotation speed | 11 r/min |
| Climbing ability | 35° |
| Grounding specific voltage | 33.3 kPa |
| Maximum digging force of the boom (ISO) | 39 kN |
| Maximum digging force of the bucket (ISO) | 57 kN |
| Length (transportation status) | 6100 mm |
| Overall width (standard track configuration) | 2167 mm |
| High (transportation status) | 2690 mm |
| chassis wheelbase | 2230 mm |
| Underframe gauge | 2845 mm |
| Track width (standard) | 450 mm |
| Maximum excavation height | 7053 mm |
| Maximum excavation radius | 6327 mm |
| Maximum excavation depth | 4111 mm |
| Maximum unloading height | 5015 mm |
